TRIM METER + TACHOMETER

Honda Marine BF75DK0 LHTA

Honda Marine
#oem кодцена
2
32161-404-000
BAND B1, WIRE | (Optional).
3
32540-ZV5-911
HARNESS ASSY., METER (A) | (Optional). Use up to Frame SN 1004849.
3
32540-ZZ3-000
HARNESS ASSY., METER (A) | (Optional). Use from Frame SN 1004850.
4
34908-MB9-871
BULB, WEDGE BASE (T10) (12V 1.7W) (STANLEY) | (Optional).
5
34908-MG9-951
BULB, WEDGE BASE (12V 1.7W) | (Optional).
6
37215-KM1-670
CLAMP | (Optional).
7
37250-ZV7-913
TACHOMETER ASSY. | (Optional).
8
37253-ZV5-821
GASKET | (Optional).
9
37256-ZV5-821
BRACKET (TO 1015209) (FROM 1015210) | (Optional).
10
37258-ZV5-821
SOCKET (TO 1015209) (FROM 1015210) | (Optional).
11
37260-ZV5-822
METER ASSY., TRIM (TO 1015209) (FROM 1015210) | (Optional).
12
37263-ZV5-821
GASKET (TO 1015209) (FROM 1015210) | (Optional).
13
37266-ZV5-821
BRACKET (TO 1015209) (FROM 1015210) | (Optional).
14
37268-ZV5-821
SOCKET (TO 1015209) (FROM 1015210) | (Optional).
15
90309-ZV5-821
NUT, HEX. (5MM) | (Optional).
16
90310-ZV5-821
NUT, HEX. (4MM) | (Optional).
17
90550-ZV5-821
WASHER, SPRING (5MM) | (Optional).
18
90560-ZV5-821
WASHER, SPRING (4MM) | (Optional).
19
98200-11000
FUSE A (10A) | (Optional).
