Gear Case 1

Honda Marine BF60AK1 LRTA

Honda Marine
#oem кодцена
1
06125-ZZ3-000
CASE KIT, GEAR | (Optional).
2
19286-ZZ3-000
PLATE, RUBBER SETTING
3
41101-ZZ3-000ZC
CASE, GEAR *NHB14M* (AQUA MARINE SILVER METALLIC)
4
41102-ZZ3-000
GROMMET, GEAR CASE
5
41104-ZZ3-010
SCREEN, R. WATER
6
41105-ZZ3-010
SCREEN, L. WATER
7
41107-ZZ5-000ZC
TAB, TRIM *NHB14M* (AQUA MARINE SILVER METALLIC)
8
41109-ZW1-B00
METAL, ANODE
9
90015-ZY3-000
BOLT, HEX. (10X60)
10
90101-ZW9-003
BOLT, OIL CHECK
11
90103-ZY3-000
BOLT, HEX. (10X32)
12
90103-ZZ3-000
SCREW, FLAT (5X37)
13
90120-ZY3-000
BOLT, DRAIN PLUG
14
90126-ZV5-000
BOLT, HEX. (8X20)
15
90205-ZY1-000
NUT, SELF-LOCK (6MM)
16
90206-HW1-671
BOLT, FLANGE (6X30)
17
90302-ZV4-000
NUT, SELF-LOCK (5MM)
19
90507-ZV4-000
WASHER, PLAIN (8MM)
20
90563-ZV5-000
WASHER, PLAIN (10MM)
21
90756-ZV5-000
PIN, DOWEL (6X10)
22
90758-ZV5-000
PIN, SPLIT (4.0) | (Optional).
23
91251-ZZ3-003
SEAL, WATER (17X36X6) | (Optional).
24
91252-ZW4-003
SEAL, WATER (22X35X7) | (Optional).
25
91254-ZY3-003
SEAL, WATER (12X21X6) | (Optional).
26
91301-ZW4-003
O-RING (6.9X1.45)
27
91301-ZW4-003
O-RING (6.9X1.45) | (Optional).
28
91351-ZZ3-000
O-RING (33.7X3.5) | (Optional).
29
91352-ZZ3-000
O-RING (76.5X3) | (Optional).
30
91359-MB0-000
O-RING (58.5X3.5) | (Optional).
