Crankshaft Piston

Honda Marine BF5AK3 SA

Honda Marine
#oem кодцена
1
13010-ZH7-004
SEE PART DETAILS - PRI; RING SET, PISTON (STD) (NIPPON)
2
13101-ZV1-000
PISTON
3
13111-ZV1-000
PIN, PISTON
4
13200-ZV1-000
ROD ASSY., CONNECTING
5
13310-ZV1-010
CRANKSHAFT
6
90001-Z1T-000
BOLT, CONNECTING ROD | Use from Engine SN 2077180.
6
90001-ZE1-000
BOLT, CONNECTING ROD | Use up to Engine SN 2077179.
7
90459-357-000
WASHER C, THRUST (25MM)
8
90551-ZE1-000
CLIP, PISTON PIN (18MM)
