Fuel Tube

Honda Marine BF150AK2 XCA

Honda Marine
#oem кодцена
1
16850-ZY6-A01
SEE PART DETAILS - PRI; TUBE A, FUEL (FKM)
1
16897-ZW9-003
CLAMP, FUEL TUBE (14.0)
2
16966-MR1-000
JOINT, FUEL TUBE
2
16860-ZY6-A00
TUBE B, FUEL
3
16871-ZY6-A00
TUBE C, FUEL
3
16966-MR5-000
JOINT, FUEL TUBE
4
16881-ZY6-A00
TUBE D, FUEL
4
17661-ZW9-900
BULB, PRIMER
5
16890-ZY6-A00
TUBE E, FUEL
5
17665-ZV5-000
VALVE, IN. | Use up to Frame SN 1400086.
5
17665-ZX2-003
VALVE, IN. | Use from Frame SN 1400087.
6
16966-MR5-000
JOINT, FUEL TUBE
6
17680-ZV4-000
VALVE, OUTLET | Use up to Frame SN 1400086.
6
17680-ZX2-003
VALVE, OUTLET | Use from Frame SN 1400087.
7
17738-ZY3-000
PLUG, FUEL TUBE
7
17700-ZX2-C01
TUBE ASSY., FUEL TANK | Use from Frame SN 1400087.
7
17700-ZY3-C03
TUBE ASSY., FUEL TANK (JOINT TYPE)(FKM) | Use up to Frame SN 1400086.
8
17701-ZY9-E04
SEE PART DETAILS - PRI; TUBE, FUEL LONG (7.3X2000) | Use from Frame SN 1400087.
8
19270-ZY3-000
NUT, WATER MOUTH
9
17702-ZY9-E03
TUBE, FUEL SHORT | Use up to Frame SN 1400086.
9
17702-ZY9-E04
TUBE, FUEL SHORT | Use from Frame SN 1400087.
9
19271-ZY3-000
JOINT, WATER HOSE
10
17703-921-010
SEE PART DETAILS - PRI; BAND, TUBE CLIP (20MM)
10
19272-ZY3-000
SEAT, WATER MOUTH
11
17704-ZV4-010
SEE PART DETAILS - PRI; BAND, TUBE CLIP (12.5MM)
11
90604-ZV0-000
CLIP, TUBE (B12)
12
90651-ZY6-000
CLIP B1, TUBE
13
95001-80001-60M
BULK HOSE, FUEL (8X1000) (8X300)
