Crankshaft Piston

Honda Marine BF150AK2 LA

Honda Marine
#oem кодцена
1
13010-ZY6-000
RING SET, PISTON (STD)
2
13101-ZY6-000
PISTON A
2
13102-ZY6-000
PISTON B
3
13111-PNA-010
PIN, PISTON
4
13115-P5A-000
CLIP, PISTON PIN
5
13204-5X6-J01
BOLT, CONNECTING ROD (SOURCE: VINTAGE PARTS INC.) | Use from Engine SN 1032882.
5
13204-P8A-A01
BOLT, CONNECTING ROD | Use up to Engine SN 1032881.
6
13210-PPA-000
ROD, CONNECTING | Use up to Engine SN 1032881.
6
13210-R40-A00
ROD, CONNECTING | Use from Engine SN 1032882.
7
13211-ZY6-004
BEARING A, CONNECTING ROD (BLUE)
7
13217-ZY6-004
BEARING G, CONNECTING ROD (RED)
7
13212-ZY6-004
BEARING B, CONNECTING ROD (BLACK)
7
13213-ZY6-004
BEARING C, CONNECTING ROD (BROWN)
7
13214-ZY6-004
BEARING D, CONNECTING ROD (GREEN)
7
13215-ZY6-004
BEARING E, CONNECTING ROD (YELLOW)
7
13216-ZY6-004
BEARING F, CONNECTING ROD (PINK)
8
13310-ZY6-000
CRANKSHAFT | Use from Engine SN 1034597.
8
13310-R40-A00
CRANKSHAFT | Use up to Engine SN 1034596.
9
13326-PNA-003
SEE PART DETAILS - PRI; BEARING F, MAIN (UPPER) (PINK) (DAIDO)
9
13325-PNA-003
SEE PART DETAILS - PRI; BEARING E, MAIN (UPPER) (YELLOW) (DAIDO)
9
13324-PNA-003
SEE PART DETAILS - PRI; BEARING D, MAIN (UPPER) (GREEN) (DAIDO)
9
13323-PNA-003
SEE PART DETAILS - PRI; BEARING C, MAIN (UPPER) (BROWN) (DAIDO)
9
13322-PNA-003
SEE PART DETAILS - PRI; BEARING B, MAIN (UPPER) (BLACK) (DAIDO)
9
13321-PNA-003
SEE PART DETAILS - PRI; BEARING A, MAIN (UPPER) (BLUE) (DAIDO)
10
13331-ZY6-013
SEE PART DETAILS - PRI; WASHER, THRUST | Use up to Engine SN 1026271.
10
13331-ZY6-023
WASHER, THRUST | Use from Engine SN 1034597.
11
13341-PNA-003
SEE PART DETAILS - PRI; BEARING A, MAIN (LOWER) (BLUE) (DAIDO)
11
13342-PNA-003
SEE PART DETAILS - PRI; BEARING B, MAIN (LOWER) (BLACK) (DAIDO)
11
13343-PNA-003
SEE PART DETAILS - PRI; BEARING C, MAIN (LOWER) (BROWN) (DAIDO)
11
13344-PNA-003
SEE PART DETAILS - PRI; BEARING D, MAIN (LOWER) (GREEN) (DAIDO)
11
13345-PNA-003
SEE PART DETAILS - PRI; BEARING E, MAIN (LOWER) (YELLOW) (DAIDO)
11
13346-PNA-003
SEE PART DETAILS - PRI; BEARING F, MAIN (LOWER) (PINK) (DAIDO)
12
13620-RAA-A02
SPROCKET, CHAIN DRIVE
13
13622-PNA-003
PLATE, CRANK PULSER
14
13811-ZY6-000
PULLEY, CRANKSHAFT
15
90017-PCX-013
BOLT-WASHER (16X49)
16
90704-PNA-000
KEY (4.5X21)
17
94301-10120
PIN, DOWEL (10X12) | Use up to Engine SN 1032881.
18
13391-ZY3-010
RETAINER, SPRING | Use from Engine SN 1037494.
18
13391-ZY3-000
RETAINER, SPRING | Use from Engine SN 1034597 to 1037493.
19
13392-ZY6-000
SEAT, SPRING (150) | Use from Engine SN 1034597.
20
13398-ZY3-003
SPRING, SUPPORT | Use from Engine SN 1034597.
21
04105-ZY6-000
WASHER KIT, THRUST (150) | Use up to Engine SN 1034596.
