Rear fender (model k8) для квадроциклов Suzuki LT-R450,Z QuadRacer R450 (2009)

Rear fender (model k8)

Suzuki LT-R450,Z QuadRacer R450

oem код

название

цена

1-1

63111-45G01-YU1

Крыло заднее

1-2

63111-45G01-30H

Крыло заднее

1-3

63111-45G01-019

Fender, Rear (lt-r450z)

Подушка

Винт

Гайка

Clip, Tray

Mudguard, Rh (black)

Mudguard, Lh (black)

Манометр

Tool Assy

11-1

68171-44B00-GY8

Emblem (for Yu1)

11-2

68171-44B00-8YM

Emblem (for 30h)

11-3

68171-44B00-BJB

Emblem, "suzuki" (lt-r450z)

12-1

68175-45G20-ENF

Tape, Rear Fende (for Yu1)

12-2

68175-45G20-ENE

Tape, Rear Fende (for 30h)

13-1

68176-45G20-ENF

Tape, Rear Fende (for Yu1)

13-2

68176-45G20-ENE

Tape, Rear Fende (for 30h)

68175-45G30-EUS

Tape, Rear Fende (lt-r450z)

68176-45G30-EUS

Tape, Rear Fende (lt-r450z Refer To Fig.42b(g-12) For Model K9 )
