Rear swingingarm (model k5)

Suzuki LT-F250 OZARK

Rear swingingarm (model k5)

#

oem код

название

цена

1

Swingingarm Set, Rear

Swingingarm Set, Rear

2

.bush, Pivot

.bush, Pivot

3

Housing, Rr Axle, R

Housing, Rr Axle, R

4

Шпилька

Шпилька

5

Гайка

Гайка

6

Bolt, Rr Swgarm Bracket, R

Bolt, Rr Swgarm Bracket, R

7

Bolt, Drive Gear

Bolt, Drive Gear

8

Гайка

Гайка

9

Bolt, Front (12x57)

Bolt, Front (12x57)

10

Гайка

Гайка

11

O Ring, Rr Axle Housing Rear

O Ring, Rr Axle Housing Rear

12

Болт

Болт

13

62100-05G10-019

Absorber Assy, Rear Shock

Absorber Assy, Rear Shock

14

Bolt, Upper (10x50)

Bolt, Upper (10x50)

15

Гайка

Гайка
