Brake lever (model f/g)
Suzuki LT250R Quad Racer 1985-1992
| # | oem код | название | цена |
|---|---|---|---|
1 | 57211-19A03-291 Рукоятка | Рукоятка | |
4 | 01500-0616A Болт | Болт | |
5 | 08321-0106A Шайба-замок | Шайба-замок | |
6 | 09169-06019 Frame Cover Was | Frame Cover Was | |
7 | 02112-05357 Screw 5x35 | Screw 5x35 | |
8 | 02112-05407 Винт | Винт | |
9 | 57420-49101 Lever Brake | Lever Brake | |
10 | 57431-05A00 Bolt Lever | Bolt Lever | |
11 | 08319-2106B Гайка | Гайка | |
12 | 09407-12402 Mud Guard Clamp | Mud Guard Clamp | |
13 | 58631-07010 Трос | Трос | |
2-1 | 57100-19A03 Case Assy Throt | Case Assy Throt | |
2-2 | 57100-19A03 Case Assy Throt | Case Assy Throt | |
3-1 | 57151-24301 Lever Throttle | Lever Throttle | |
3-2 | 57151-24301 Lever Throttle | Lever Throttle |
