Блок цилиндров

Arctic Cat DVX 250

Arctic Cat
#oem кодцена
1
3304-008
Bolt Stud 8mm
2
3303-626
Crank Case Comp R (inc. 3)
3
3304-065
Cone Type Plug 6*7
4
3303-628
Gasket Crank Case A
5
3304-342
Nut Rr Shaft
6
3304-091
Oil Seal 25*40*8
7
3304-198
Brg Ball Radial 6304/20*52*15
8
3304-191
Bolt Flange Sh 6*50
9
3304-221
Crank Case Comp L
10
3304-195
Brg Radial Ball 6205
11
3304-699
Brg Ball Radial 6204
12
3304-074
Brg Needle 20*26*16
13
3304-067
Brg Ball 6305
14
3304-079
Oil Seal 27*42*7
15
3304-052
Bolt Drain Plug Special
16
3304-205
Ball Steel 12
17
3304-063
Spg Bolt Seat Inner
18
3304-021
Washer Bolt Seat
19
3304-109
Bolt Seat Ball Stopper
20
3303-365
Bolt Flange 8*12
21
3303-381
Bolt Flange Sh 6*12
22
3304-158
Clip 2*100
23
3304-005
Bolt Special 6*10 96600-08010 N.c.
24
3304-040
Plate Brg Holder
25
3304-009
Bolt B Stud 8mm
26
3303-642
Gasket L Cover
27
3303-843
Clamper Wire Harness
28
3304-698
Sw Assy Gear Change
29
3304-187
Bolt Flange 6*10
30
3304-073
Bearing Ball Radial
31
3303-632
Cover Left
32
3304-003
Bolt Flange Shf 6*28
33
3304-101
Gasket Starting Cover
34
3303-341
Pin Dowel 8*14
35
3304-225
Cover Starting
36
3304-190
Bolt Flange Sh 6*32
37
3303-384
Bolt Flange Sh 6*25
38
3304-222
Cover L Cover
39
3304-407
Screw Pan 6*12
40
3304-004
Bolt Flange Shf 6*40
41
3304-039
Plate Brg Holder
