Передний капот

Sea-Doo (Bombardier) Sportster LE, 5769

Sea-Doo (Bombardier)
#oem кодцена
269500056
Miroir Ass.ga. *mirror-assy.lh
1
204100065
Ergot D Ancrage*stud-latch
2
232100600
Гайка шестиугольная DIN.439B-A2
3
234002600
Шайба
4
291000628
Шайба
5
232501600
Гайка
6
204070238
Люверс
7
269500170
Couv.bagage Sup*cover-stor.upp
8
269500227
Couv.bagage Inf*cover-stor.low
9
269500055
Miroir Ass.dr. *mirror-assy.rh Includes 9 - 11.
11
269500079
Rotule Miroir *mirror Joint
12
269500082
Ressort Miroir *spring-mirror
13
232661600
Nut-wing Ansi B18.17 Type A
14
293150008
Заклепка 3/16
15
213200016
Washer-flat Emhart
16
241140060
Винт K40 X 10
17
293550010
Graisse Synth. *grease-synth.
18
204620281
Charniere Ass.*hinge Assy.
19
293150039
Заклепка 3/16
20
207151260
Винт
21
232551600
Гайка
22
269500107
Plaque Retenue *plate-retainer
23
241141660
Винт K40 X 16
24
204620237
Deflecteur *deflector
25
269500172
Boitier Miroir *housing-rh.
26
269500173
Boitier Miroir *housing-lh.
27
269700076
Couv.loquet *cover-latch
28
269700109
Loquet Assemble*latch Ass Y
29
269700077
Levier Loquet *lever-latch
30
269700017
Ressort Loquet *spring-latch
31
234061600
Шайба
32
207163560
Винт
33
269500252
Logement Ecrou *housing-nut As Includes 33 - 34.
34
232561600
Гайка стопорная эластичная 985-A2
35
293200020
Anneau Etanche *seal-tray
36
269500241
Couv.acces Ass.*cover-acc.assy Includes 36 - 37.
37
293200033
Anneau Etanche *seal-tray
38
204620049
Ressort Charn. *spring-hinge
39
207152560
Винт
40
234051600
Шайба
42
269500416
Coffre Bagage *tray-storage
43
293250037
Прокладка
44
269500606
Boitier Extinct*housing-exting
45
269500603
Cap Extincteur *cap-extinguish
46
293150032
Заклепка
47
234032600
Шайба
48
204630050
Douille Hex. *wrench-socket
