L.a. sleeve cylinder sleeves
Engine. Engine
- Sleeves are constructed of an alloy of carbon chrome, and molydenum of 200 brinell hardness
- This construction insures ease of installation, trouble free boring and dependable long engine life
- Sleeves are all centerless ground for perfect roundness to one-half thousandth of an inch or less
- All sleeves include porting
- AC - Original cylinder bore is alloy-chrome plated, nikasil or electrofused. The cylinder must be bored to accept the new cylinder sleeve
- CS - Original block has a cast-in sleeve liner in the cylinder. The cylinder must be bored out to accept the new cylinder sleeve. The cast-in liner will be bored completely out of the cylinder. Do not try to push out the cast-in liner, cylinder damage may be the result
- CI - Original block has a cast-in iron liner in the cylinder. The cylinder must be bored to accept the new cylinder sleeve. When using a 1/16" wall sleeve, the cast-in liner will not be completely removed. The sleeve is designed to insert into the iron lined cylinder
- RS - Original block has a replacement sleeve. Heat the cylinder to remove the sleeve. Reheat the cylinder to install the new cylinder sleeve
| деталь | цена | |
|---|---|---|
CYL SLEEVE- KAW INTRUDER + 440- FC- 436CC 68MM | 12 639.00р под заказ | |
CYL SLEEVE- INVADER 440LC LIQUIFIRE LC '78-80 | 12 639.00р под заказ | |
| FL1093 CYL SLEEVE- 340TX FA-'76- 79- 335CC 62MM | --- Цена неизвестна | |
CYL SLEEVE-5000FC '85-88+ 76-78- CHEETAH/PNTH | 12 639.00р под заказ | |
CYL SLEEVE- SPIRIT 5000FA 78-80- 499CC 70MM | 12 639.00р под заказ | |
CYL SLEEVE- JD 440 FC 79- 82- KAW 440 DRIFTER FC | 13 138.00р под заказ | |
| FL1118 CYL SLEEVE-MXZ 380FC '01- 06- GSX/GTX 380FC '05-06 | --- Цена неизвестна | |
(SPEC ORD) SLEEVE S/M | 13 637.00р под заказ | |
(SPEC ORD) S/M SLEEVE | 11 703.00р под заказ | |
| FL1126 CYL SLEEVE- ROTAX 521LC + 82-90 534-537 9700 '82-90 | --- Цена неизвестна | |
CYL SLEEVE-SS440 FC'79-83 YAM- 431CC 66MM | 14 302.00р под заказ | |
| FL1132 CYL SLEEVE- SRV/XLV 540 80-91 YAMAHA | --- Цена неизвестна | |
CYL SLEEVE-INDY 400/488CC BIG BORE 488CC 72MM | 13 138.00р под заказ | |
CYL SLEEVE- 462(MX) LC + 85-95- FORMULA ST 94-95+ | 13 138.00р под заказ | |
CYL SLEEVE- PHAZER 480 + 84-98- VT480 '91-98 | 15 019.00р под заказ | |
| FL1158 CYL SLEEVE- 570 EXCITER + 87-91 LC 569CC 73MM | --- Цена неизвестна | |
CYL SLEEVE-ARCTIC 500'86- 90- CHEETAH- COUGAR | 11 974.00р под заказ | |
CYL SLEEVE-650 WILDCAT + 88-90- LC- 650CC 78MM | 3 079.00р под заказ | |
SLEEVE SNOW ZL550/ESR'00- 03- PNTRA 550 '02-05 + | 14 321.00р под заказ | |
| FL1178 CYL SLEEVE-WILDCAT'91-96+ MTN CAT '91-96 | --- Цена неизвестна | |
CYL SLEEVE-EXCITER II'90- 93 ST | 12 639.00р под заказ | |
| FL1180 CYL SLEEVE-INDY 650 RX + 91-97 | --- Цена неизвестна | |
| FL1181 CYL SLEEVE- MACH I LC'91- 92 617CC ROTAX SKI DOO | --- Цена неизвестна | |
CYL SLEEVE- XCR 440'92-94 INDY 440 SKS '95-96 | 12 639.00р под заказ | |
| FL1183 CYL SLEEVE-YAM V-MAX 4 + 92-94 | --- Цена неизвестна | |
CYL SLEEVE-POL XLT580'93- 95 | 12 639.00р под заказ | |
CYL SLEEVE-THUNDERCAT'93- 97- MNT CAT '93-97 | 13 138.00р под заказ | |
CYL SLEEVE- ZL580 '00 + PANTERA 580 '95-00-EXT580 | 12 639.00р под заказ | |
| FL1194 CYL SLEEVE- MACH I LC'93- 95- MACH II/XTC '93-95 + | --- Цена неизвестна | |
| FL1197 CYL SLEEVE- V-MAX 500'94- 96 | --- Цена неизвестна | |
| FL1198 CYL SLEEVE- V-MAX 600'94- 96 | --- Цена неизвестна | |
CYL SLEEVE- CAT ZR440'94- 95 | 12 639.00р под заказ | |
CYL SLEEVE-EXT580/MC '95- 98- ZR580 '94-97 | 14 321.00р под заказ | |
CYL SLEEVE-OVRBORE ZRT800 95-01- PANTERA '98-99 | 14 302.00р под заказ | |
CYL SLEEVE- XCR600 '95-96 INDY | 12 639.00р под заказ | |
CYL SLEEVE- 440 MXZ'95-97 | 12 639.00р под заказ | |
| FL1209 CYL SLEEVE- XLT600 '95-99 CLASSIC/TOURING | --- Цена неизвестна | |
CYL SLEEVE- V-MAX 800'95- 97 | 11 974.00р под заказ | |
CYL SLEEVE-ULTRA/SP'96-98 680CC | 11 974.00р под заказ | |
CYL SLEEVE- ZRT600 LC'96- 02- EXT600 '97-98 + | 11 974.00р под заказ | |
CYL SLEEVE-XCR 600/SE'97- 98- INDY XCE SP '96 | 11 974.00р под заказ | |
| FL1214 CYL SLEEVE-600 FORM III LC 96-99 | --- Цена неизвестна | |
| FL1215 CYL SLEEVE- 800 INDY + STORM SE/SKS LC '96-98 | --- Цена неизвестна | |
SLEEVE SNOW 500 SPORT/SWT/ WT'95-03+MXZ 500FC'01-02+ | 14 321.00р под заказ | |
| FL1217 CYL SLEEVE- ZL440 '97-00+ PANTHER LC '96-97-JAG '96 | --- Цена неизвестна | |
CYL SLEEVE-440 ZR LC '96- 98 | 11 974.00р под заказ | |
CYL SLEEVE- 440 XCF'97-98 | 12 639.00р под заказ | |
SLEEVE SNOW INDY 700 RMK/ SKS'97-04-700 PRO X '03- | 15 019.00р под заказ | |
CYL SLEEVE- OVERBORE INDY 700 RMK/SKS'97-05-PRO-X | 14 302.00р под заказ | |
FL1222 CYL SLEEVE- 800 MACH Z/LT 97-03- TOUR 800 '99-01 + | -- под заказ | |
CYL SLEEVE- 583 MX Z + 96-98 | 13 138.00р под заказ | |
| FL1224 SLEEVE SNOW 500 FORMULA/ + SLS'96-03+MXZ 500 '02-03+ | --- Цена неизвестна | |
CYL SLEEVE- 700 MACH I + 97-00- GRAND TOUR '99-00 | 12 639.00р под заказ | |
| FL1226 CYL SLEEVE- VT700 '99-03+ MM700 MNTN MAX '99-04 + | --- Цена неизвестна | |
| FL1227 SLEEVE SNOW VMAX 600'97-98 VENTURE LC '97-98-MM600 98-99 | --- Цена неизвестна | |
CYL SLEEVE-500 V-MAX XT/+ XTC- VENTURE LC '97-00 + | 13 827.00р под заказ | |
CYL SLEEVE- INDY XC/RMK + 98-01- XCSP '99-XCDLX 00 | 12 639.00р под заказ | |
CYL SLEEVE- ZL/ZR500/EFI 98-02- MC 50OEFI '01-02+ | 11 974.00р под заказ | |
CYL SLEEVE- ZR600 '98-00 ARCTIC- BRIDGED EXHAUST | 11 974.00р под заказ | |
CYL SLEEVE- VK540/II/III 88-04 YAMAHA | 13 827.00р под заказ | |
| FL1242 CYL SLEEVE-MXZ380 '01-02+ LEGEND '02 + | --- Цена неизвестна | |
| FL1246 CYL SLEEVE- Z 440 '99-06 S/M | --- Цена неизвестна | |
| FL1249 CYL SLEEVE- 700 POWDER SPEC 99-00 ZL 700 ZR 700 S/M | --- Цена неизвестна | |
| FL1250 CYL SLEEVE- XCF 440 '99 + INDY 440 PRO X '02-03 | --- Цена неизвестна | |
CYL SLEEVE-TRAIL RMK/SS/ 99-07- INDY 550 CLSC'02-06 | 13 827.00р под заказ | |
CYL SLEEVE-INDY 500 XC + 99-03+INDY 500 CLASS'03+ | 12 639.00р под заказ | |
CYL SLEEVE-SKNDC 600 '01- 08- MXZ TNT 500SS '08-09+ | 14 903.00р под заказ | |
| FL1256 CYL SLEEVE-MXZ670 HO '99+ SUMMIT X 670 '99 | --- Цена неизвестна | |
CYL SLEEVE-PHAZER 500 99- 01- VENTURE XL '99-00 + | 14 671.00р под заказ | |
CYL SLEEVE- 500 XC/SP'00- 07 POLARIS | 11 974.00р под заказ | |
CYL SLEEVE- INDY 800 RMK 00-05-'08- PRO X '03-04+ | 14 321.00р под заказ | |
CYL SLEEVE- LEGEND SPORT/ GS'02-04- MXZ 700 '00-03+ | 14 321.00р под заказ | |
CYL SLEEVE- ZR/ZL800 '01- 03-PNTRA 800EFI '02-04 + | 12 639.00р под заказ | |
CYL SLEEVE-MXZ 800 SE'03+ MXZ800/RER/RENGADE'01-07+ | 15 019.00р под заказ | |
CYL SLEEVE- Z570/SS/ESR+ 02-07- PNTHR 570/ESR '02-07 | 13 827.00р под заказ | |
| FL1271 CYL SLEEVE- PNTRA 600EFI+ 02-05-M/CAT 600EFI '01-04 | --- Цена неизвестна | |
CYL SLEEVE- F5 F/CAT '03- 09- LXR '07-09- T500 '08-09 | 11 974.00р под заказ | |
| FL1273 CYL SLEEVE- F7 F/CAT '03- 06- SBRCT 700 '04-06 + | --- Цена неизвестна | |
| FL1274 CYL SLEEVE- ZR900 '03-06+ MOUNTAIN CAT 900 '03-06 + | --- Цена неизвестна | |
CYL SLEEVE-MXZ 550FC '03- 09- SMMT 550FC '03-09 + | 14 671.00р под заказ | |
CYL SLEEVE-GSX 600'04-08+ SMMT 600 HO ADRNLN'03-08 | 14 321.00р под заказ | |
CYL SLEEVE- XCR800 '00-03 INDY POLARIS | 11 974.00р под заказ | |
CYL SLEEVE-CAT F6 '04-08+ CRSSFRE 6 '06-09- M6'07-09 | 14 321.00р под заказ | |
| FL1286 CYL SLEEVE- SD GTX SPRT + 500'05-07-MXZ TRL 500'01-07 | --- Цена неизвестна | |
| FL1288 CYL SLEEVE-900FUSION/RMK/ SWITCHBACK '05-06 | --- Цена неизвестна | |
CYL SLEEVE-600 XS/SP '02- 06- RMK'02-08-SWTCBK'04-09 | 14 321.00р под заказ | |
CYL SLEEVE- MACH Z 1000 + 05-07- RNGD '06-07 + | 15 019.00р под заказ | |
CYL SLEEVE- 800R '07-09 SKI DOO | 14 671.00р под заказ | |
