Comet 108-exp high-performance clutches
Drivetrain. Drivetrain
- Designed for more power, more endurance, more of everything you need for speed - and now accept OEM starter rings for electric starters
- Tried, tested and built to handle high-horsepower engines
- Consistently smooth shifting even after hours of use
- Wider rollers for increased bearing area (33% more)
- 1997 and newer 108-EXP clutches include special recessed mounting bolt with special pilot washer
- Each features a bushing in the movable face and redesigned fixed face for increased durability
- Uncalibrated clutches are sold without cam arms and spring
NOTE: A flush bore depth indicates the taper begins exactly at the inner edge of the fixed face casting. Positive (+) numbers indicate the taper starts the specified distance into the casting; while negative (-) numbers indicate the taper begins in an extension out of the fixed face casting. Belt width can be adjusted on clutch models that list more than one dimension. Std. = Clutch is pre-set to the belt width listed. Opt. = Clutch can be adjusted to the belt width listed.
| деталь | цена | |
|---|---|---|
33mm tapered flush, 1:10 taper with Arctic Cat gear bosses with 33mm crankshaft (accepts OEM ring gear for electric start models) - Belt Width: 1 3/8” (std.)/ 1 1/4” (opt.) | 40 394.00р под заказ | |
30mm tapered flush w/ Arctic Cat gear bosses (accepts OEM ring gear for electric start models) - Belt Width: 13 /8” (std.)/ 1 1/4” (opt.) | 40 394.00р под заказ | |
30mm tapered flush with Polaris gear bosses (accepts OEM ring gear for electric start models, not for use on models with 33mm shaft) - Belt Width: 1 3/8” (std.)/ 1 1/4” (opt.) | 40 394.00р под заказ | |
30mm tapered +1.02”, 7.5:1 taper with Ski-Doo gear bosses (accepts OEM ring gear for electric start models) - Belt Width: 1 3/8” (std.)/ 1 1/4” (opt.) | 40 394.00р под заказ | |
30mm tapered flush with Yamaha gear bosses (accepts OEM ring gear for electric start models) - Belt Width: 1 3/8” (std.)/ 1 1/4” (opt.) | 40 394.00р под заказ | |
30mm tapered flush with Ski-Doo gear bosses (accepts OEM ring gear for electric start models) - Belt Width: 1 3/8” (std.)/ 1 1/4” (opt.) | 40 394.00р под заказ | |
217504 30mm tapered +.200” Ski-Doo deep bore - Belt Width: 1 3/8” (std.)/ 1 1/4” (opt.) | -- под заказ | |
30mm tapered -.140” shallow bore - Belt Width: 1 1/4” (std.)/ 1 3/8” (opt.) | 40 394.00р под заказ | |
